Dimensions: 305 x 138 x 65 mm (L x W x H)
Height: 3.25 slot
GPU: GeForce RTX 4070 Ti
Chip: AD104-400
Manufacturing: 4 nm
Base clock: 2310 MHz
Boost clock (Standard mode): 2730 MHz
Boost clock (OC mode): 2760 MHz
Shader units (CUDA cores ): 7,680
Memory size: 12,288 MB
Memory clock: 2,625 (21,000 effective) MHz
Type: GDDR6X
Memory connection: 192 bit
Memory bandwidth: 504 GB/s
Slot: PCIe x16 (PCIe/PCIe 2.x/PCIe 3.0/PCIe 4.0)
Connections:
3x DisplayPort 1.4a
1x HDMI 2.1a
Power supply: 1x 16-pin PCIe 5.0 (12VHPWR)
TDP: 285 watts
Recommended power supply unit output: min. 600 watts
Features: DirectX 12 Ultimate, OpenGL 4.6, Vulkan RT API, VR Ready, G-SYNC HDR, NVIDIA GPU Boost 4.0, HDCP 2.3, NVIDIA Surround, 3D Vision, Tessellation, PhysX, DLSS 3, CUDA, NVENC Encoder 8, NVENC Decoder 5, AV1, Adaptive Vertical Sync, VXGI, Super Resolution, 4K Ultra HD Support, SMP, NVIDIA ShadowPlay, Real-Time Ray Tracing
